ASTM A1008 Cold Rolled Steel Sheet
ASTM A1008 Cold Rolled Steel Sheet
A1008 steel sheet is a low-carbon cold rolled steel produced in strict accordance with ASTM A1008/A1008M standards. It offers a smooth surface, uniform thickness, and excellent dimensional accuracy.
Compared to HRPO (hot rolled pickled and oiled) steel, ASTM A1008 cold rolled steel provides higher precision, better surface finish, and improved consistency for applications like stamping, laser cutting, and painting. With superior formability, weldability, and mechanical strength, A1008 is ideal for applications requiring excellent surface quality, including automotive body panels, home appliance casings, and structural components. Multiple grade options are available, including ASTM A1008 CS Type B (deep drawing quality), DC01–DC04 (JIS/EU hardness equivalents), and equivalents to legacy ASTM A366 as well as Chinese GB standards Q235 and Q345.
Compared to HRPO (hot rolled pickled and oiled) steel, ASTM A1008 cold rolled steel provides higher precision, better surface finish, and improved consistency for applications like stamping, laser cutting, and painting. With superior formability, weldability, and mechanical strength, A1008 is ideal for applications requiring excellent surface quality, including automotive body panels, home appliance casings, and structural components. Multiple grade options are available, including ASTM A1008 CS Type B (deep drawing quality), DC01–DC04 (JIS/EU hardness equivalents), and equivalents to legacy ASTM A366 as well as Chinese GB standards Q235 and Q345.
Product Specifications
| Dimension Name | Value |
| Thickness | 0.20 – 5.10 mm (0.008″–0.200″); customizable up to 6 mm; typical gauges 16–30 |
| Width | 600 – 2000 mm (24″–78″); standard width: 1000 – 1250 mm |
| Length | Sheets: up to 12 m; coils: any length; plates from coil thickness up to ~25 mm |
| Chemical Composition (ASTM A1008) | C ≤ 0.15 %, Mn ≤ 0.60 %, P ≤ 0.035 %, S ≤ 0.040 % (Source: FastMetals) |
| Chemical Composition (JIS SPCC / DC01) | C ≤ 0.12 %, Mn ≤ 0.50 %, P ≤ 0.040 %, S ≤ 0.045 % (Source: Alibaba) |
| Mechanical Properties (ASTM A1008) | Tensile Strength: 380–550 MPa (55–80 ksi); Yield Strength: 240–415 MPa (35–60 ksi); Elongation ≥ 23–30% (Source: fastmetals.com) |
| Available Grades | Multiple grade options are available under ASTM A1008 CS Type A / Type B / Type C, as well as Drawing Steel (DS) and Deep Drawing Steel (DDS / EDDS) grades. These are comparable to EN 10130 DC01–DC06, JIS SPCC / SPCD / SPCE, and legacy ASTM A366 specifications. In Chinese standards, GB Q195, Q235, and Q345 cold rolled steel serve as equivalents for reference. |
| Surface Treatment | Cold rolled smooth finish (2B/2D); light oil or dry; skin-passed; pickled & oiled (P&O); mill or slit edge |
| Material Form | Coil / Sheet / Plate |
Need A Custom Quote
Or more information about this product? Contact our sales staff today!
More Details
- Key Features of A1008 Steel Sheets
- Typical Applications of A1008 Steel Sheet
- Why Choose Zhaojian Steel for ASTM A1008 Sheets
Key Features of A1008 Steel Sheets
Strict ASTM Compliance:
Produced in full compliance with ASTM A1008/A1008M standards, guaranteeing consistent mechanical and material properties..
Superior Formability:
The low carbon content and precise cold rolling process make A1008 CS steel perfect for deep drawing and bending applications.
Excellent Weldability:
Optimized chemical makeup ensures strong, clean welds using common welding techniques, reducing defects and improving fabrication efficiency.
Smooth Surface Finish:
The cold rolling process delivers a uniform, clean surface that is perfect for painting, galvanizing, or other surface treatments.
Wide Range of Sizes and Finishes:
Available in multiple finishes (P&O, black annealed, dry, or oiled), ASTM A1008 steel sheets meet diverse manufacturing requirements.
Typical Applications of A1008 Steel Sheet
（1）Automotive Industry
Applications: Outer body panels, fuel tanks, seat frames
Why A1008: High formability and surface finish allow for complex shapes and painting
（2）Construction
Applications: Drywall framing, structural studs, brackets
Why A1008: Dimensional consistency and easy weldability
（3）Home Appliances
Applications: Washer/dryer panels, refrigerator liners, oven backs
Why A1008: Clean finish and good corrosion resistance (with coating)
（4）General Manufacturing
Applications: Electrical enclosures, shelving, office furniture
Why A1008: Easy stamping, bending, and spot welding
Why Choose Zhaojian Steel for ASTM A1008 Sheets
Zhaojian Steel supplies ASTM A1008 cold rolled steel sheets and coils globally, providing:
-
Full compliance with ASTM A1008/A1008M specifications
-
Customizable dimensions, edge condition, and coating
-
Certificates including MTC EN 10204 3.1, SGS, and ISO 9001
-
Fast lead time, competitive pricing, and OEM packaging options
