medium carbon steel sheet
medium carbon steel sheet
Medium carbon steel sheet contains approximately 0.3% to 0.6% carbon, achieving a good balance between strength, hardness, and ductility. Compared to low-carbon steel, it offers higher strength and wear resistance, while providing better cost efficiency than alloy steel. It is well-suited for heat treatment and machining.
Common applications include components requiring moderate strength and durability, such as gears, shafts, automotive parts, and structural machinery.
Zhaojian Steel offers a range of medium carbon steel grades, including 1040, 1045, 1050, and 1055, available in both hot-rolled and cold-rolled forms to meet diverse processing and application needs.
Medium Carbon Steel Sheet Specification
| Parameter | Specification |
|---|---|
| Carbon Content | 0.3% – 0.6% |
| Available Grades | AISI 1040, 1045, 1050, 1055, etc |
| Thickness Range | 1.5mm – 20mm (customizable) |
| Width Range | 1000mm – 2000mm (customizable) |
| Length Range | 2000mm – 6000mm or custom cut |
| Delivery Condition | Hot Rolled (HR), Cold Rolled (CR), Annealed, or As Rolled |
| Tensile Strength | 550 – 750 MPa (depending on grade and treatment) |
| Yield Strength | 350 – 500 MPa |
| Elongation | 10% – 20% |
| Heat Treatment Options | Normalizing, Annealing, Quenching & Tempering |
| Surface Finish | Mill finish, pickled & oiled, or custom surface treatment |
| Standards | ASTM A830, JIS G4051 (S45C), GB/T 699 (45#) |
Quality Certification
Applications of Medium Carbon Steel Sheet
Construction machinery: Base plates, frames, and reinforcements.
Automotive parts: Chassis, underbody panels, and clutch plates.
Mechanical components: Blanks for gears and clutch parts after heat treatment.
Industrial tools: Agricultural blades and die backing plates.
Structural parts: Sprocket bases and support plates.
Railway and bridge use: Bridge decks and rail seat plates.
More Details About Zhaojian Steel Products
Key Features
Quality Assurance
Strict control of carbon content and microstructure ensures a balance of strength and ductility.
Heat Treatment Processes
Supports normalizing, quenching and tempering, and other treatments to meet diverse mechanical performance needs.
High-Quality Export Packaging
Steel straps with buckles and protective inner and outer corners ensure product integrity.
Medium Carbon Steel Sheet Manufacturing Process
Rolling and Forming
Steel billets are processed into sheets by:
Hot Rolling – Heated billets are rolled into thick sheets with high efficiency and a slightly rough surface.
Cold Rolling – Hot-rolled sheets are further compressed at room temperature for better precision and surface finish.
Optional Surface Treatments
Pickling + Oiling – Removes scale and prevents rust.
Shot Blasting – Prepares surface for coating.
Skin Pass – Improves surface appearance.
Heat Treatment Options
Normalizing – Refines grain and relieves stress, improving structural reliability.
Annealing – Softens cold-rolled sheets for easier forming or stamping.
Quenching & Tempering (Q&T) – Increases hardness and strength for high-load parts like gears or dies.
FAQ
Medium carbon steel sheet itself has limited corrosion resistance and typically requires coatings, galvanization, or other surface treatments to improve durability.
Yes, the thickness, width, length, and surface treatment of medium carbon steel sheets can all be customized according to customer requirements.
